DESCRIPTION

TASSCO XT wear plate provides the ideal combination of hardness, toughness, while maintaining weldability, and formability. Precision alloy chemistry and advanced quench-and-temper techniques ensure consistent hardness and wear resistance for most difficult conditions. Vacuum degassing removes excess hydrogen and carbon, enhancing cleanliness and mechanical performance, while low sulfur levels improve toughness and durability.

APPLICATIONS

• Bucket liners
• Chute and Hopper Liners
• Truck Bed Liners
• Replaceable Back Elbows
• Cutting Edges
• Screens

CHARACTERISTICS

• Quench, Tempered, and Thru Hardened
• Excellent depth of hardness achieved by balanced use of Chromium, Molybdenum, and Manganese
• High Impact Resistance

SPECIFICATIONS

• Low Carbon Range (0.20 - 0.23)
• Aim 470 BHN (450 - 514 BHN) in plates 3/16” - 1”
• Low Sulfur (0.003 Max)

AVAILABILITY

• 3/16” - 1” in standard plates 96” - 288” (3/16” thru 3/4”) and 96” X 240” (1”)
• Custom thicknesses and plate sizes available upon request
